SS360NT Magnetic Field Strength Sensor 24 Vdc , 4 Pin SMD Ammonia Leak Detection Sensor

Model Number : SS360NT

Place of Origin : USA

MOQ : 1

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability : 1000000pcs/Month

Delivery Time : 3-5Workingdays

Packaging Details : Standard Box

Package / Case : SOT-23-3

Package : Cut Tape

Output voltage : - 0.5 V to + 26 V

Unit weight : 63 mg

Contact Now

SS360NT Board Interface Hall Effect Magnetic Sensor Latching Digital

FEATURES
• Fastest response time in its class
• No-chopper-stabilization
• High sensitivity
• Latching magnetics
• Wide operating voltage range of 3 Vdc to 24 Vdc
• Built-in reverse voltage
• Durable design
• RoHS-compliant material meets Directive 2002/95

POTENTIAL APPLICATIONS
Industrial/commercial
• Brushless dc motor commutation
• Speed and RPM sensing in electric motors and fans
• Tachometer, counter pickup
• Robotics control
• Flow-rate sensing for appliances

Transportation
• Brushless dc motor commutation
• Electronic window lift, anti-pinch power window systems
• Vehicle convertible roof position
Medical
• Medical equipment using electric motors

Type	Bipolar
Operating supply current	3.5 mA
Maximum output current	20 mA
Operating Point Min/Max	5 G, 55 G
Min/Max Release Point (Brp)	- 55 G, - 5 G
Operating supply voltage	24 V
Minimum operating temperature	- 40 C
Maximum operating temperature	+ 150 C
Installation style	SMD/SMT
