Working current 5mA ZE16-CO Electrochemical Carbon Monoxide Gas Module with Output data UART output

Model Number : ZE16-CO

Place of Origin : CN

MOQ : 1

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability : 5000pcs

Delivery Time : 3-5work days

Packaging Details : Paper box

Detection gas : Carbon Monoxide（CO gas）

Interfering gases : Alcohol, etc.

Output data : UART output

Working voltage : 5V (DC)

Working current : <5mA

Preheating time : 30 seconds

Contact Now

ZE16-CO Electrochemical Carbon Monoxide Gas Module

Description:

ZE16-CO is a general-purpose and miniaturization electrochemical carbon monoxide detection module. It utilizes electrochemical principle to detect CO in air which makes the module with high selectivity and stability. Built-in temperature sensor can do temperature compensation; and it has digital output and analog voltage output. It is a combination of mature electrochemical detection principle and sophisticated circuit design.

Application:

For residential occasions to detect CO concentration, smart home.

Features:

Supply different output ways: UART, analog voltage, etc.

Specifications:

Model No. ZE16-CO
Detection gas Carbon Monoxide(CO gas)
Interfering gases Alcohol, etc.
Output data UART output
Working voltage 5V (DC)
Working current <5mA
Preheating time 30 seconds
Response time ≤30 seconds
Recovery time ≤30 seconds
Detection range 0～500ppm
Resolution 1ppm
Working temperature -10℃～55℃
Working humidity 15%RH-90%RH(no condensation)
Storage temperature -10℃～55℃
Life span 2 years(in air)
