MC114C Catalytic Flammable Gas Sensor Standard Encapsulation Metallurgy powder mesh for Safe Gas Monitoring

Model Number : MC114/MC114C

Place of Origin : CN

MOQ : 1

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability : 5000pcs

Delivery Time : 3-5work days

Packaging Details : Paper box

Model : MC114/ MC114C

Sensor Type : Catalytic

Standard Encapsulation : Metal, Metallurgy powder mesh

Working voltage(V) : 2.5±0.1

Working current(mA) : MC114: 150±10; MC114C: 90±10

Measuring range(%LEL) : 0~100

Contact Now

MC114/MC114C Catalytic Flammable Gas Sensor

Profile :

MC114/ MC114C adopts catalytic combustion principle, and its two arms of electric bridge consists of a test element and a compensate element. The resistance of the test element rises once it meets the combustible gases, in the same time, the output voltage of the bridge changes and the voltage variation rises in direct proportion to the gas concentration. The compensate element, as a conference, has the function of compensating temperature and humidity.

Features:

It has good sensitivity to methane in wide range, and has advantages such as long lifespan, low cost and simple drive circuit &etc. The bridge output is linear, quick response, good repeatability and selectivity, good stability, excellent resistance to the interference of H2S gas and organosilicone.

Main Applications:

It is widely used in industrial occasion to detect the concentration of natural gas, LPG,coal gas and alkanes. It is also used in combustible gas leakage alarm system, combustible gas detector and gas concentration meter and so on.

Model MC114/ MC114C
Sensor type Catalytic
Standard encapsulation Metal, Metallurgy powder mesh
Working voltage(V) 2.5±0.1
Working current(mA) MC114:150±10; MC114C: 90±10
Sensitivity (mV) 1% CH4 15~35
1% C3H8 20~50
Linearity ≤5%
Measuring range (%LEL) 0~100
Response time (90%) ≤10s
Recovery time (90%) ≤30s
Working environment -40 ~+70℃, less than 95%RH
Storage environment -20 ~+70℃, less than 95%RH
Size (mm) MC114: 19×9.5×14; MC114C: 14×8×10
Life span 3 years
Anti-explosion Mark ExdibⅠ
