H101-CO2-Z8S-U-40kP Photoacoustic PAS Carbon Dioxide CO2 Sensor with Peak Current of 300 mA 5 V

Model Number : H101-CO2-Z8S-U-40kP

Place of Origin : CN

MOQ : 1

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability : 5000pcs

Delivery Time : 3-5work days

Packaging Details : Paper box

Detection Gas : CO₂

Peak Current : 300 mA (@5 V)

Interface Level : 3.3 V

Output Signal : UART (TTL 3.3 V)

Warm-up Time : 60 s

Response Time T63％ : < 60 s

Contact Now

H101-CO2-Z8S-U-40kP Photoacoustic PAS Carbon Dioxide CO2 Sensor

Description:

The H101-CO2-Z8S-U-40kP CO₂ gas sensor, hereinafter referred to as the PAS sensor, is a compact sensor with a wide measurement range. Employing the photoacoustic principle, it effectively detects CO₂ in the air. The sensor features excellent selectivity, operates independently of oxygen, and has an extended lifespan. With built-in temperature and humidity compensation, it offers enhanced usability. The PAS sensor represents a high-performance design, integrating photoacoustic spectroscopy detection technology with sophisticated circuit design and advanced algorithms. Its dimensions measure 20x15x7.8mm, making it suitable for space - constrained applications.

Application:

Automotive Air Conditioning Systems: Enables precise control of cabin air quality by monitoring CO₂ levels.
Air Purification Devices: Facilitates efficient purification by detecting CO₂ concentrations and triggering purification mechanisms.
Air Quality Monitoring Equipment: Plays a crucial role in providing accurate CO₂ data for comprehensive air quality assessment.
Smart Homes: Allows for intelligent control of home environments based on CO₂ levels, enhancing comfort.
Fresh Air Systems: Helps regulate the intake of fresh air by sensing indoor CO₂ levels.

Features:

Wide Range: Offers a measurement range of 400 - 5000 ppm, extendable up to 40000 ppm.
High Sensitivity: Capable of detecting even minute changes in CO₂ concentrations.
Stability: Demonstrates excellent long - term stability.
Compensation and Output: Features temperature and humidity compensation, ensuring a linear output.
Output Interface: Provides a UART (TTL 3.3V) output interface for easy integration.
Long Lifespan: Has a lifespan of over 10 years.
Resistance: Resistant to water vapor interference and immune to poisoning.

Specifications:

Parameter	Details
Model	H101-CO2-Z8S-U-40kP
Detection Gas	CO₂
Supply Voltage	Light source: (5.0±0.05) V; System: (3.3±0.3) V
Average Current	<15 mA (@5 V); <2 mA (@3.3 V)
Peak Current	300 mA (@5 V)
Interface Level	3.3 V
Measurement Range	400 - 5000 ppm (expandable to 40000 ppm)
Output Signal	UART (TTL 3.3 V)
Warm-up Time	60 s
Response Time T63％	< 60 s
Operating Temperature	-10～60 ℃
Pressure Range	750～1150 hPa
Operating Humidity	0～95%RH (non - condensing)
Storage Temperature	5～40 ℃
Lifespan	>10 years
Accuracy (400 - 2000 ppm)	Resolution: 10 ppm; Accuracy: ±(50 ppm + 3% reading)
Accuracy (2001 - 5000 ppm)	Accuracy: ±(40 ppm + 3% reading)

H101-CO2-Z8S-U-40kP Photoacoustic PAS Carbon Dioxide CO2 Sensor with Peak Current of 300 mA 5 V
