Model Number : S6931-01

Place of Origin : Japan

MOQ : 1

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability : 5000pcs

Delivery Time : 3-5work days

Packaging Details : Paper box

Light-receiving side : 2.4 × 2.8 mm

encapsulation : plastics

Cooling : Non-cooled

Reverse voltage (max) : 10 V

Dark current (max) : 20 pA

Rise Time (Typical) : 0.5 μs

Contact Now

Silicon photodiodes S6931-01

Silicon photodiodes molded into clear plastic packages

Features - Visible to near-infrared wavelength band (suppressed infrared sensitivity type)

Spectral sensitivity characteristics

S6931-01 Silicon Photodiodes Molded Into Clear Plastic Packages

Light sensitivity (typical)	0.48 A/W
Dark current (max)	20 pA
Rise Time (Typical)	0.5 μs
Junction Capacitance (typical)	200 pF

S6931-01 Silicon Photodiodes Molded Into Clear Plastic Packages
