7E4-NH3-10 PN: 059-3500-200 FOUR ELECTRODE NH3 Gas SENSOR

Model Number : 7E4-NH3-10 PN: 059-3500-200

MOQ : 1

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Delivery Time : 3-5 work days

Nominal Range : 0 ~ 10 ppm

Maximum Overload : 50 ppm

Sensitivity (20°C) : 0.20 ± 0.05 μA/ppm

Response Time (T90) : ≤ 120 s

Zero Signal (20°C) : < ±0.1 μA

Baseline Shift (-30°C ~ 50°C) : < 1 ppm

Contact Now

7E4-NH3-10 PN: 059-3500-200 FOUR ELECTRODE NH3 Gas SENSOR

Description:

This 4-electrode sensor is designed for air quality monitoring to mea- sure the low-concentration NH3 gas with ultra-high resolutions. The de- sign optimizes the sensor sensitivity, accuracy and long-term stability and enables the sensor to detect NH3 variations at parts per billion (ppb) levels.

Installation:

Output signals from the sensor pins are different. Inappropriate use of the pins in product design will affect the sensor functionality. Exposure to high concentrations of solvent vapors should be avoided under any condition. Mechanical overstress may cause deformation or cracks of the plastic enclosure of the sensor. If the sensor is used in extreme environmental conditions, please contact us for more details.

Temperature Range	-30°C ~ 50°C
Pressure Range	1 ± 0.1 atm
Humidity Range	15% ~ 90%RH non-condensing
Long Time Output Drift	< 10% signal/year
Recommended Storage Temp	10°C ~ 30°C
Expected Operating Life	2 years in clean air
Storage Life	6 months in original packaging
Warranty	24 months

7E4-NH3-10 PN: 059-3500-200 FOUR ELECTRODE NH3 Gas SENSOR
